Key specs
Suzuki Jimny (Off-road vehicle) Jimny IV 2018,2019,2020,2021,2022,2023,2024
What is the body type, Suzuki Jimny IV 1.5 (102 Hp) ALLGRIP PRO Automatic 2018?
Off-road vehicle, 3 Doors, 4 Seats
How much power, Suzuki Jimny IV 1.5 (102 Hp) ALLGRIP PRO Automatic 2018?
102 Hp @ 6000 rpm.
69.8 Hp/l
What is the engine size, Suzuki Jimny IV 1.5 (102 Hp) ALLGRIP PRO Automatic 2018?
1462 cm3
89.22 cu. in.
How many cylinders, Suzuki Jimny IV 1.5 (102 Hp) ALLGRIP PRO Automatic 2018?
4,
Inline
What is the drivetrain, Suzuki Jimny IV 1.5 (102 Hp) ALLGRIP PRO Automatic 2018?
All wheel drive (4x4),
How long is this vehicle, Suzuki Jimny IV 1.5 (102 Hp) ALLGRIP PRO Automatic 2018?
3645 mm
143.5 in.
How wide is the vehicle, Suzuki Jimny IV 1.5 (102 Hp) ALLGRIP PRO Automatic 2018?
1645 mm
64.76 in.
What is the curb weight, Suzuki Jimny IV 1.5 (102 Hp) ALLGRIP PRO Automatic 2018?
1110-1135 kg
2447.13 - 2502.25 lbs.
Suzuki Jimny (Off-road vehicle) Jimny IV 2018,2019,2020,2021,2022,2023,2024 Specs
General information
| Brand |
Suzuki |
| Model |
Jimny (Off-road vehicle) |
| Version |
Jimny IV |
| Engine version |
1.5 (102 Hp) ALLGRIP PRO Automatic |
| Year production start |
2018 |
| Vehicle type |
Off-road vehicle |
| Horsepower RPM |
102 Hp @ 6000 rpm. |
| Curb weight kg -lbs total |
1110-1135 kg
2447.13 - 2502.25 lbs.
|
| Overall length mm - inch |
3645 mm
143.5 in.
|
| Doors |
3 |
Engine specs
| Designation model |
K15B |
| Engine position and orientation |
Front, Longitudinal |
| Cylinders |
4 |
| Position of cylinders |
Inline |
| Displacement (liters) |
1462 cm3
89.22 cu. in.
|
| Eng. horsepower RPM |
102 Hp @ 6000 rpm.
|
| Horsepower per litre |
69.8 Hp/l
|
| Weight / horsepower kg/hp - hp/tons |
10.9 kg/Hp
91.9 Hp/tonne
|
| Weight / torque kg/Nm - Nm/tons |
8.5 kg/Nm, 117.1 Nm/tonne
8.5 kg/Nm
117.1 Nm/tonne
|
| Torque Nm RPM lb-ft RPM |
130 Nm @ 4000 rpm.
95.88 lb.-ft. @ 4000 rpm.
|
| Bore (mm in) |
74 mm
2.91 in.
|
| Stroke (mm in) |
85 mm
3.35 in.
|
| Compression ratio |
10 |
| Fuel delivery system |
Multi-point indirect injection |
| Fuel type |
Petrol (Gasoline) |
| Valvetrain |
4 |
| Engine aspiration |
Naturally aspirated engine |
| Engine oil liters | quarts |
3.9 l
4.12 US qt | 3.43 UK qt
|
| Engine coolant |
4.9 l
5.18 US qt | 4.31 UK qt
|
| Powertrain architecture |
Internal Combustion engine |
| Engine location |
Front, Longitudinal
|
Transmission and Drive system
| Drive configuration |
All wheel drive (4x4)
|
Brakes
| Front brakes |
Disc |
| Rear brakes |
Drum |
| Anti-lock brake system |
ABS (Anti-lock braking system) |
Steering
| Steering type |
Cone worm with recirculation balls |
| Turning diameter m - ft |
9.8 m
32.15 ft.
|
Suspension
| Front suspension |
Coil spring, Rigid axle suspension |
| Rear suspension |
Helical spring, Rigid axle suspension |
Wheels & Tyres
| Wheels size |
195/80 R15
|
| Wheels rims |
15 |
Passenger
| Passengers seats |
4 |
| Trunk space min liter | cu. Ft. |
85 l
3 cu. ft.
|
| Trunk space max liter | cu. Ft. |
830 l
29.31 cu. ft.
|
Dimensions
| Overall length mm - inch |
3645 mm
143.5 in.
|
| Overall width mm -inch |
1645 mm
64.76 in.
|
| Overall height mm -inch |
1725 mm
67.91 in.
|
| Wheelbase mm - inch |
2250 mm
88.58 in.
|
| Track width front mm - inch |
1395 mm
54.92 in.
|
| Track width rear mm - inch |
1405 mm
55.31 in.
|
Weights
| Curb weight kg -lbs total |
1110-1135 kg
2447.13 - 2502.25 lbs.
|
| Gross weight kg -lbs total |
1435 kg
3163.63 lbs.
|
| Capacities kg - lbs |
300-325 kg
661.39 - 716.5 lbs.
|
| Fuel tank liters | gallons |
40 l
10.57 US gal | 8.8 UK gal
|
Engine type
4 CYLINDER INLINE
