Key specs
Mercedes-Benz B-class (Hatchback) B-class (W247) 2020,2021,2022
What is the body type, Mercedes-Benz B-class (W247) B 180d (116 Hp) 2020?
Hatchback, 5 Doors, 5 Seats
How much power, Mercedes-Benz B-class (W247) B 180d (116 Hp) 2020?
116 Hp @ 3400 rpm.
59.5 Hp/l
How fast is the car, Mercedes-Benz B-class (W247) B 180d (116 Hp) 2020?
200 km/h 124.27 mph
What is the engine size, Mercedes-Benz B-class (W247) B 180d (116 Hp) 2020?
1950 cm3
119 cu. in.
How many cylinders, Mercedes-Benz B-class (W247) B 180d (116 Hp) 2020?
4,
Inline
What is the drivetrain, Mercedes-Benz B-class (W247) B 180d (116 Hp) 2020?
Front wheel drive,
How long is this vehicle, Mercedes-Benz B-class (W247) B 180d (116 Hp) 2020?
4419 mm
173.98 in.
How wide is the vehicle, Mercedes-Benz B-class (W247) B 180d (116 Hp) 2020?
1796 mm
70.71 in.
What is the curb weight, Mercedes-Benz B-class (W247) B 180d (116 Hp) 2020?
1436 kg
3165.84 lbs.
Mercedes-Benz B-class (Hatchback) B-class (W247) 2020,2021,2022 Specs
General information
| Brand |
Mercedes-Benz |
| Model |
B-class (Hatchback) |
| Version |
B-class (W247) |
| Engine version |
B 180d (116 Hp) |
| Year production start |
2020 |
| Year production end |
2022 |
| Vehicle type |
Hatchback |
| Horsepower RPM |
116 Hp @ 3400 rpm. |
| Acceleration 0 - 100 kmh sec |
10.4 sec |
| Curb weight kg -lbs total |
1436 kg
3165.84 lbs.
|
| Overall length mm - inch |
4419 mm
173.98 in.
|
| Doors |
5 |
| Top Speed |
200 km/h 124.27 mph |
Engine specs
| Designation model |
OM 654q DE 20 SCR |
| Cam configuration |
DOHC
|
| Engine position and orientation |
Front, Transverse |
| Cylinders |
4 |
| Position of cylinders |
Inline |
| Displacement (liters) |
1950 cm3
119 cu. in.
|
| Eng. horsepower RPM |
116 Hp @ 3400 rpm.
|
| Horsepower per litre |
59.5 Hp/l
|
| Weight / horsepower kg/hp - hp/tons |
12.4 kg/Hp
80.8 Hp/tonne
|
| Weight / torque kg/Nm - Nm/tons |
5.1 kg/Nm, 195 Nm/tonne
5.1 kg/Nm
195 Nm/tonne
|
| Torque Nm RPM lb-ft RPM |
280 Nm @ 1750 rpm.
206.52 lb.-ft. @ 1750 rpm.
|
| Bore (mm in) |
82 mm
3.23 in.
|
| Stroke (mm in) |
92.3 mm
3.63 in.
|
| Fuel delivery system |
Diesel Commonrail |
| Fuel type |
Diesel |
| Valvetrain |
4 |
| Engine aspiration |
Turbocharger, Intercooler |
| Emission certification |
EURO 6D-ISC-FCM
|
| Powertrain architecture |
Internal Combustion engine |
| Engine location |
Front, Transverse
|
Transmission and Drive system
| Drive configuration |
Front wheel drive
|
| Transmission |
6 |
Brakes
| Front brakes |
Ventilated discs |
| Rear brakes |
Disc |
| Anti-lock brake system |
ABS (Anti-lock braking system) |
Steering
| Steering type |
Steering rack and pinion |
| Turning diameter m - ft |
11 m
36.09 ft.
|
Suspension
| Front suspension |
Independent type McPherson |
| Rear suspension |
Torsion |
Wheels & Tyres
| Wheels size |
205/60 R16; 205/55 R17
|
| Wheels rims |
6.5J x 16; 6.5J x 17 |
Passenger
| Passengers seats |
5 |
| Trunk space min liter | cu. Ft. |
445 l
15.72 cu. ft.
|
| Trunk space max liter | cu. Ft. |
4530 l
159.98 cu. ft.
|
| Roof load load kg lbs |
75 kg
165.35 lbs.
|
Dimensions
| Overall length mm - inch |
4419 mm
173.98 in.
|
| Overall width mm -inch |
1796 mm
70.71 in.
|
| Overall height mm -inch |
1562 mm
61.5 in.
|
| Wheelbase mm - inch |
2729 mm
107.44 in.
|
| Track width front mm - inch |
1567 mm
61.69 in.
|
| Track width rear mm - inch |
1547 mm
60.91 in.
|
Weights
| Curb weight kg -lbs total |
1436 kg
3165.84 lbs.
|
| Gross weight kg -lbs total |
2051 kg
4521.68 lbs.
|
| Capacities kg - lbs |
615 kg
1355.84 lbs.
|
| Fuel tank liters | gallons |
43 l
11.36 US gal | 9.46 UK gal
|
Fuel economy
| Urban (NEDC) l/100 km - Mpg |
6.2-6.7 l/100 km
37.94 - 35.11 US mpg
|
| Extra urban (NEDC) l/100 km - Mpg |
3.8-4.2 l/100 km
61.9 - 56 US mpg
|
| Combined (NEDC) l/100 km - Mpg |
4.7-5.1 l/100 km
50.05 - 46.12 US mpg
|
| Autonomy km (combined use) NEDC |
914?893617 |
Engine type
4 CYLINDER INLINE
