Roadster, 2 Doors, 2 Seats
14.7 l/100 km 16 US mpg
16.8 l/100 km 14 US mpg
13.1 l/100 km 17.96 US mpg
765 Hp @ 7500 rpm.
191.5 Hp/l
330 km/h 205.05 mph
3994 cm3
243.73 cu. in.
8, V-engine
Rear wheel drive,
4600 mm
181.1 in.
#N/D
1388 kg
3060.02 lbs.
| Brand | McLaren |
|---|---|
| Model | 765LT (Roadster) |
| Version | 765LT Spider |
| Engine version | 4.0 V8 (765 Hp) SSG |
| Year production start | 2021 |
| Vehicle type | Roadster |
| Horsepower RPM | 765 Hp @ 7500 rpm. |
| Acceleration 0 - 100 kmh sec | 2.8 sec |
| Curb weight kg -lbs total |
1388 kg3060.02 lbs. |
| Overall length mm - inch |
4600 mm181.1 in. |
| Doors | 2 |
| Top Speed | 330 km/h 205.05 mph |
| Designation model | M840T |
|---|---|
| Cam configuration | DOHC, VVT |
| Engine position and orientation | Middle, Longitudinal |
| Cylinders | 8 |
| Position of cylinders | V-engine |
| Displacement (liters) |
3994 cm3243.73 cu. in. |
| Eng. horsepower RPM | 765 Hp @ 7500 rpm. |
| Horsepower per litre | 191.5 Hp/l |
| Weight / horsepower kg/hp - hp/tons |
1.8 kg/Hp551.2 Hp/tonne |
| Weight / torque kg/Nm - Nm/tons | 1.7 kg/Nm, 576.4 Nm/tonne
1.7 kg/Nm576.4 Nm/tonne |
| Torque Nm RPM lb-ft RPM |
800 Nm @ 5500 rpm.590.05 lb.-ft. @ 5500 rpm. |
| Fuel delivery system | Direct injection |
| Fuel type | Petrol (Gasoline) |
| Valvetrain | 4 |
| Engine aspiration | Twin-Turbo, Intercooler |
| Powertrain architecture | Internal Combustion engine |
| Engine location | Middle, Longitudinal |
| Drive configuration | Rear wheel drive |
|---|
| Front brakes | Ventilated discs, 390 mm |
|---|---|
| Rear brakes | Ventilated discs, 380 mm |
| Anti-lock brake system | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
|---|
| Front suspension | Double wishbone |
|---|---|
| Rear suspension | Double wishbone |
| Wheels size | Front wheel tires: 24535 R19 |
|---|---|
| Wheels rims | Front wheel rims: 8J x 19 |
| Passengers seats | 2 |
|---|---|
| Trunk space min liter | cu. Ft. |
150 l5.3 cu. ft. |
| Overall length mm - inch |
4600 mm181.1 in. |
|---|---|
| Overall height mm -inch |
1192 mm46.93 in. |
| Wheelbase mm - inch |
2670 mm105.12 in. |
| Track width front mm - inch |
1659 mm65.31 in. |
| Track width rear mm - inch |
1617 mm63.66 in. |
| Curb weight kg -lbs total |
1388 kg3060.02 lbs. |
|---|---|
| Fuel tank liters | gallons |
72 l19.02 US gal | 15.84 UK gal |
| City l/100km - mpg |
16.8 l/100 km14 US mpg |
|---|---|
| Highway l/100 km - mpg |
13.1 l/100 km17.96 US mpg |
| Combined l/100 km - Mpg |
14.7 l/100 km16 US mpg |
| Autonomy km (combined use) | 514 |
| Combined fuel consumption (WLTP) | 12.3 l/100 km 19.12 US mpg |
8 CYLINDER V-Engine
It's an engine with eight cylinder piston where the cylinders share a common crankshaft and are arranged in a V configuration.
What is the 8 cylinder V-engine displacement: it is in a range between 2926 cc and 8135 cc in recent model line up powertrain.
How much is the power of the 8 cylinder V-engine: the power of the 8 cylinder V-engine is in a range from 125 bhp to 1160 bhp.
Which cars use 8 cylinder V-engine: in recent years several manufactures have been used the V8 engine for 3 main applications: premium, sport cars and lightweight trucks. 8 V engine is the American preferred engine for iconic giant pick-up.
What is the eight cylinder V angle: the majority of V8 engines use a V-angle of 90 degrees. This angle results in good engine balance and low vibrations. The downside is a larger powertrain body that makes the use of this configuration suitable only for longitudinal position and rear drive wheels traction.
V8 engines with a 60 degree V-angle were used in the 1996-1999 by Ford and in 2005-2011 by Volvo. The Ford engine used a 60 degree V-angle because it was based on a V6 engine with a 60 degree V-angle. Both the Ford and Volvo engines were used in transverse engine chassis, which were designed for a front-wheel-drive layout. To reduce the vibrations caused by the unbalanced 60 degree V-angle, Volvo's used a balance shaft and offset split crankpins.
The Rolls-Royce Meteorite tank engine also used a 60 degree V-angle, since it was derived from the 60 degree V12 Rolls-Royce Meteor which in turn was based on the famous Rolls-Royce Merlin V12 engine.
Most V8 engines fitted to road cars use a cross-plane crankshaft, since this configuration produces less vibration due to the perfect primary balance and secondary balance.
The rumbling exhaust sound produced by a typical cross-plane V8 engine is partly due to the uneven firing order within each of the two banks of four cylinders and with separate exhaust systems for each bank of cylinders, this uneven pulsing creates the legendary rumbling sound that is typically of V8 engines.
edited by arrabbiata
