Station wagon (estate), 5 Doors, 5 Seats
113 Hp @ 6000 rpm.
75.4 Hp/l
1498 cm3
91.41 cu. in.
4, Inline
Front wheel drive,
4200 mm
165.35 in.
1695 mm
66.73 in.
#N/D
| Brand | Mazda |
|---|---|
| Model | Familia (Station wagon (estate)) |
| Version | Familia Wagon |
| Engine version | 1.5 i (113 Hp) |
| Year production start | 2002 |
| Year production end | 2004 |
| Vehicle type | Station wagon (estate) |
| Horsepower RPM | 113 Hp @ 6000 rpm. |
| Overall length mm - inch |
4200 mm165.35 in. |
| Doors | 5 |
| Cam configuration | OHC |
|---|---|
| Engine position and orientation | Front, Transverse |
| Cylinders | 4 |
| Position of cylinders | Inline |
| Displacement (liters) |
1498 cm391.41 cu. in. |
| Eng. horsepower RPM | 113 Hp @ 6000 rpm. |
| Horsepower per litre | 75.4 Hp/l |
| Torque Nm RPM lb-ft RPM |
140 Nm @ 4000 rpm.103.26 lb.-ft. @ 4000 rpm. |
| Bore (mm in) |
78 mm3.07 in. |
| Stroke (mm in) |
78.4 mm3.09 in. |
| Compression ratio | 9.4 |
| Fuel delivery system | Multi-point indirect injection |
| Fuel type | Petrol (Gasoline) |
| Valvetrain | 4 |
| Engine aspiration | Naturally aspirated engine |
| Powertrain architecture | Internal Combustion engine |
| Engine location | Front, Transverse |
| Drive configuration | Front wheel drive |
|---|
| Front brakes | Ventilated discs |
|---|---|
| Rear brakes | Drum |
| Passengers seats | 5 |
|---|
| Overall length mm - inch |
4200 mm165.35 in. |
|---|---|
| Overall width mm -inch |
1695 mm66.73 in. |
| Overall height mm -inch |
1420 mm55.91 in. |
| Wheelbase mm - inch |
2610 mm102.76 in. |
| Track width front mm - inch |
1470 mm57.87 in. |
| Track width rear mm - inch |
1470 mm57.87 in. |
| Gross weight kg -lbs total |
1170 kg2579.41 lbs. |
|---|---|
| Fuel tank liters | gallons |
50 l13.21 US gal | 11 UK gal |
