Sedan, 4 Doors, 5 Seats
115 Hp @ 6500 rpm.
72 Hp/l
1598 cm3
97.52 cu. in.
4, Inline
Front wheel drive,
4335 mm
170.67 in.
1695 mm
66.73 in.
#N/D
| Brand | Mazda |
|---|---|
| Model | Familia (Sedan) |
| Version | Familia |
| Engine version | 1.6 i (115 Hp) |
| Year production start | 1994 |
| Year production end | 1998 |
| Vehicle type | Sedan |
| Horsepower RPM | 115 Hp @ 6500 rpm. |
| Overall length mm - inch |
4335 mm170.67 in. |
| Doors | 4 |
| Cam configuration | DOHC |
|---|---|
| Engine position and orientation | Front, Longitudinal |
| Cylinders | 4 |
| Position of cylinders | Inline |
| Displacement (liters) |
1598 cm397.52 cu. in. |
| Eng. horsepower RPM | 115 Hp @ 6500 rpm. |
| Horsepower per litre | 72 Hp/l |
| Torque Nm RPM lb-ft RPM |
135 Nm @ 5500 rpm.99.57 lb.-ft. @ 5500 rpm. |
| Bore (mm in) |
78 mm3.07 in. |
| Stroke (mm in) |
83.6 mm3.29 in. |
| Compression ratio | 9.4 |
| Fuel delivery system | Multi-point indirect injection |
| Fuel type | Petrol (Gasoline) |
| Valvetrain | 4 |
| Engine aspiration | Naturally aspirated engine |
| Powertrain architecture | Internal Combustion engine |
| Engine location | Front, Longitudinal |
| Drive configuration | Front wheel drive |
|---|
| Front brakes | Ventilated discs |
|---|---|
| Rear brakes | Drum |
| Turning diameter m - ft |
9.6 m31.5 ft. |
|---|
| Passengers seats | 5 |
|---|
| Overall length mm - inch |
4335 mm170.67 in. |
|---|---|
| Overall width mm -inch |
1695 mm66.73 in. |
| Overall height mm -inch |
1420 mm55.91 in. |
| Wheelbase mm - inch |
2605 mm102.56 in. |
| Track width front mm - inch |
1460 mm57.48 in. |
| Track width rear mm - inch |
1460 mm57.48 in. |
| Gross weight kg -lbs total |
1040 kg2292.81 lbs. |
|---|---|
| Fuel tank liters | gallons |
50 l13.21 US gal | 11 UK gal |
