Key specs
Mazda CX-9 (SUV) CX-9 II 2016,2017,2018,2019,2020,2021,2022,2023
What is the body type, Mazda CX-9 II 2.5 SKYACTIV-G (250 Hp) Automatic 2016?
SUV, 5 Doors, 7 Seats
What is the fuel economy, Mazda CX-9 II 2.5 SKYACTIV-G (250 Hp) Automatic 2016?
10.6 l/100 km 22.19 US mpg
8.4 l/100 km 28 US mpg
How much power, Mazda CX-9 II 2.5 SKYACTIV-G (250 Hp) Automatic 2016?
250 Hp @ 5000 rpm.
100.5 Hp/l
What is the engine size, Mazda CX-9 II 2.5 SKYACTIV-G (250 Hp) Automatic 2016?
2488 cm3
151.83 cu. in.
How many cylinders, Mazda CX-9 II 2.5 SKYACTIV-G (250 Hp) Automatic 2016?
4,
Inline
What is the drivetrain, Mazda CX-9 II 2.5 SKYACTIV-G (250 Hp) Automatic 2016?
Front wheel drive,
How long is this vehicle, Mazda CX-9 II 2.5 SKYACTIV-G (250 Hp) Automatic 2016?
5065 mm
199.41 in.
How wide is the vehicle, Mazda CX-9 II 2.5 SKYACTIV-G (250 Hp) Automatic 2016?
1969 mm
77.52 in.
What is the curb weight, Mazda CX-9 II 2.5 SKYACTIV-G (250 Hp) Automatic 2016?
1837 kg
4049.89 lbs.
Mazda CX-9 (SUV) CX-9 II 2016,2017,2018,2019,2020,2021,2022,2023 Specs
General information
| Brand |
Mazda |
| Model |
CX-9 (SUV) |
| Version |
CX-9 II |
| Engine version |
2.5 SKYACTIV-G (250 Hp) Automatic |
| Year production start |
2016 |
| Year production end |
2023 |
| Vehicle type |
SUV |
| Horsepower RPM |
250 Hp @ 5000 rpm. |
| Curb weight kg -lbs total |
1837 kg
4049.89 lbs.
|
| Overall length mm - inch |
5065 mm
199.41 in.
|
| Doors |
5 |
Engine specs
| Engine position and orientation |
Front, Transverse |
| Cylinders |
4 |
| Position of cylinders |
Inline |
| Displacement (liters) |
2488 cm3
151.83 cu. in.
|
| Eng. horsepower RPM |
250 Hp @ 5000 rpm.
|
| Horsepower per litre |
100.5 Hp/l
|
| Weight / horsepower kg/hp - hp/tons |
7.3 kg/Hp
136.1 Hp/tonne
|
| Weight / torque kg/Nm - Nm/tons |
5.9 kg/Nm, 168.8 Nm/tonne
5.9 kg/Nm
168.8 Nm/tonne
|
| Torque Nm RPM lb-ft RPM |
310 Nm @ 2000 rpm.
228.64 lb.-ft. @ 2000 rpm.
|
| Bore (mm in) |
89 mm
3.5 in.
|
| Stroke (mm in) |
100 mm
3.94 in.
|
| Compression ratio |
10.5 |
| Fuel delivery system |
Direct injection |
| Fuel type |
Petrol (Gasoline) |
| Valvetrain |
4 |
| Engine aspiration |
Turbocharger |
| Engine oil liters | quarts |
4.8 l
5.07 US qt | 4.22 UK qt
|
| Engine coolant |
9.9 l
10.46 US qt | 8.71 UK qt
|
| Powertrain architecture |
Internal Combustion engine |
| Engine location |
Front, Transverse
|
Transmission and Drive system
| Drive configuration |
Front wheel drive
|
Brakes
| Front brakes |
Ventilated discs |
| Rear brakes |
Disc |
| Anti-lock brake system |
ABS (Anti-lock braking system) |
Steering
| Steering type |
Steering rack and pinion |
| Turning diameter m - ft |
11.8 m
38.71 ft.
|
Suspension
| Front suspension |
Independent, Spring McPherson, with stabilizer |
| Rear suspension |
Multi-link independent |
Wheels & Tyres
| Wheels size |
255/60 R18; 255/50 R20
|
| Wheels rims |
8J x 18; 8.5J x 20 |
Passenger
| Passengers seats |
7 |
| Trunk space min liter | cu. Ft. |
407 l
14.37 cu. ft.
|
| Trunk space max liter | cu. Ft. |
2017 l
71.23 cu. ft.
|
Dimensions
| Overall length mm - inch |
5065 mm
199.41 in.
|
| Overall width mm -inch |
1969 mm
77.52 in.
|
| Overall height mm -inch |
1716-1753 mm
67.56 - 69.02 in.
|
| Wheelbase mm - inch |
2930 mm
115.35 in.
|
| Track width front mm - inch |
1659 mm
65.31 in.
|
| Track width rear mm - inch |
1656 mm
65.2 in.
|
Weights
| Curb weight kg -lbs total |
1837 kg
4049.89 lbs.
|
| Fuel tank liters | gallons |
72 l
19.02 US gal | 15.84 UK gal
|
Fuel economy
| City l/100km - mpg |
10.6 l/100 km
22.19 US mpg
|
| Highway l/100 km - mpg |
8.4 l/100 km
28 US mpg
|
Engine type
4 CYLINDER INLINE
