Key specs
KIA Stonic (Crossover) Stonic (facelift 2020) 2020,2021,2022,2023,2024
What is the body type, Kia Stonic (facelift 2020) 1.2 (84 Hp) 2020?
Crossover, 5 Doors, 5 Seats
How much power, Kia Stonic (facelift 2020) 1.2 (84 Hp) 2020?
84 Hp @ 6000 rpm.
70.2 Hp/l
How fast is the car, Kia Stonic (facelift 2020) 1.2 (84 Hp) 2020?
165 km/h 102.53 mph
What is the engine size, Kia Stonic (facelift 2020) 1.2 (84 Hp) 2020?
1197 cm3
73.05 cu. in.
How many cylinders, Kia Stonic (facelift 2020) 1.2 (84 Hp) 2020?
4,
Inline
What is the drivetrain, Kia Stonic (facelift 2020) 1.2 (84 Hp) 2020?
Front wheel drive,
How long is this vehicle, Kia Stonic (facelift 2020) 1.2 (84 Hp) 2020?
4140 mm
162.99 in.
How wide is the vehicle, Kia Stonic (facelift 2020) 1.2 (84 Hp) 2020?
1760 mm
69.29 in.
What is the curb weight, Kia Stonic (facelift 2020) 1.2 (84 Hp) 2020?
1080-1183 kg
2380.99 - 2608.07 lbs.
KIA Stonic (Crossover) Stonic (facelift 2020) 2020,2021,2022,2023,2024 Specs
General information
| Brand |
Kia |
| Model |
Stonic (Crossover) |
| Version |
Stonic (facelift 2020) |
| Engine version |
1.2 (84 Hp) |
| Year production start |
2020 |
| Vehicle type |
Crossover |
| Horsepower RPM |
84 Hp @ 6000 rpm. |
| Acceleration 0 - 100 kmh sec |
13.5 sec |
| Curb weight kg -lbs total |
1080-1183 kg
2380.99 - 2608.07 lbs.
|
| Overall length mm - inch |
4140 mm
162.99 in.
|
| Doors |
5 |
| Top Speed |
165 km/h 102.53 mph |
Engine specs
| Designation model |
G4LG |
| Cam configuration |
DOHC
|
| Engine position and orientation |
Front, Transverse |
| Cylinders |
4 |
| Position of cylinders |
Inline |
| Displacement (liters) |
1197 cm3
73.05 cu. in.
|
| Eng. horsepower RPM |
84 Hp @ 6000 rpm.
|
| Horsepower per litre |
70.2 Hp/l
|
| Weight / horsepower kg/hp - hp/tons |
12.9 kg/Hp
77.8 Hp/tonne
|
| Weight / torque kg/Nm - Nm/tons |
9.2 kg/Nm, 109.3 Nm/tonne
9.2 kg/Nm
109.3 Nm/tonne
|
| Torque Nm RPM lb-ft RPM |
118 Nm @ 4200 rpm.
87.03 lb.-ft. @ 4200 rpm.
|
| Bore (mm in) |
71 mm
2.8 in.
|
| Stroke (mm in) |
75.6 mm
2.98 in.
|
| Compression ratio |
11 |
| Fuel delivery system |
Multi-point indirect injection |
| Fuel type |
Petrol (Gasoline) |
| Valvetrain |
4 |
| Engine aspiration |
Naturally aspirated engine |
| Engine oil liters | quarts |
3.4 l
3.59 US qt | 2.99 UK qt
|
| Engine coolant |
5.4 l
5.71 US qt | 4.75 UK qt
|
| Emission certification |
Euro 6d-ISC-FCM
|
| Powertrain architecture |
Internal Combustion engine |
| Engine location |
Front, Transverse
|
Transmission and Drive system
| Drive configuration |
Front wheel drive
|
| Transmission |
5 |
Brakes
| Front brakes |
Ventilated discs, 280 mm |
| Rear brakes |
Disc, 262 mm |
| Anti-lock brake system |
ABS (Anti-lock braking system) |
Steering
| Steering type |
Steering rack and pinion |
| Turning diameter m - ft |
10.4 m
34.12 ft.
|
Suspension
| Front suspension |
Independent type McPherson, Transverse stabilizer |
| Rear suspension |
Helical spring, Elastic beam |
Wheels & Tyres
| Wheels size |
185/65 R15; 195/55 R16; 205/55 R17
|
| Wheels rims |
6J x 15; 6J x 16; 6.5J x 17 |
Passenger
| Passengers seats |
5 |
| Trunk space min liter | cu. Ft. |
352 l
12.43 cu. ft.
|
| Trunk space max liter | cu. Ft. |
1155 l
40.79 cu. ft.
|
| Roof load load kg lbs |
70 kg
154.32 lbs.
|
Dimensions
| Overall length mm - inch |
4140 mm
162.99 in.
|
| Overall width mm -inch |
1760 mm
69.29 in.
|
| Overall height mm -inch |
1520 mm
59.84 in.
|
| Wheelbase mm - inch |
2580 mm
101.57 in.
|
| Track width front mm - inch |
1531-1537 mm
60.28 - 60.51 in.
|
| Track width rear mm - inch |
1539-1544 mm
60.59 - 60.79 in.
|
Weights
| Curb weight kg -lbs total |
1080-1183 kg
2380.99 - 2608.07 lbs.
|
| Gross weight kg -lbs total |
1600 kg
3527.4 lbs.
|
| Capacities kg - lbs |
417-520 kg
919.33 - 1146.4 lbs.
|
| Fuel tank liters | gallons |
45 l
11.89 US gal | 9.9 UK gal
|
Fuel economy
| Urban (NEDC) l/100 km - Mpg |
6.6 l/100 km
35.64 US mpg
|
| Extra urban (NEDC) l/100 km - Mpg |
4.7 l/100 km
50.05 US mpg
|
| Combined (NEDC) l/100 km - Mpg |
5.4 l/100 km
43.56 US mpg
|
| Autonomy km (combined use) NEDC |
833?3333333 |
| Combined fuel consumption (WLTP) |
6.1 l/100 km 38.56 US mpg |
Engine type
4 CYLINDER INLINE
