Independent, type McPherson with coil spring and anti-roll bar
Rear suspension
Independent multi-link spring suspension with stabilizer
Body / Chassis
Wheels & Tyres
Wheels size
225/50 R18
Wheels rims
7.5J x 18
Exterior
Interior
Safety and Security
Passenger
Passengers seats
5
Trunk space min liter | cu. Ft.
401 l
14.16 cu. ft.
Roof load load kg lbs
80 kg
176.37 lbs.
Dimensions
Overall length mm - inch
4855 mm
191.14 in.
Overall width mm -inch
1880 mm
74.02 in.
Overall height mm -inch
1495 mm
58.86 in.
Wheelbase mm - inch
2950 mm
116.14 in.
Track width front mm - inch
1635 mm
64.37 in.
Track width rear mm - inch
1644 mm
64.72 in.
Coefficient of drag
0.21
Weights
Curb weight kg -lbs total
1775-1833 kg
3913.21 - 4041.07 lbs.
Gross weight kg -lbs total
2280 kg
5026.54 lbs.
Capacities kg - lbs
447-505 kg
985.47 - 1113.33 lbs.
Fuel economy
Engine type
Electric
Electric - Bev
A battery-powered electric car is an automobile which is propelled by electric motors.
Although electric cars often give good acceleration and have generally acceptable
top speed, the lower specific energy of production batteries available compared
with carbon-based fuels means that electric cars need big batteries to
increase miles range and recharging can also take much more time than average.
Electric - PHEV
A plug-in hybrid electric vehicle (PHEV) is a hybrid electric vehicle whose battery
pack can be recharged by plugging a charging cable into an external electric power
source, in addition to internally by its on-board internal combustion engine-powered
generator. Compared to conventional hybrid electric vehicles (HEVs), PHEVs have
a larger battery pack that can be charged from the power grid, which is also more
efficient.
A PHEV's battery pack is smaller than all-electric vehicles for the same vehicle
weight, but has the auxiliary option of switching back to using its gasoline/diesel
engine like a conventional HEV if the battery runs low.
Electric - FCEV
A fuel cell electric vehicle (FCEV) is an electric vehicle that uses a fuel cell,
sometimes in combination with a small battery or supercapacitor, to power its
onboard electric motor. Fuel cells in vehicles generate electricity generally
using oxygen from the air and compressed hydrogen. Most fuel cell vehicles are
classified as zero-emissions vehicles that emit only water and heat.
As compared with internal combustion vehicles, hydrogen vehicles centralize pollutants at
the site of the hydrogen production, where hydrogen is typically derived from
reformed natural gas.
Electric - PFCEV
This vehicle is very similar to Fuel Cell Electric Vehicle but has a socket and
can be recharged from the grid. Battery likely is significantly larger - comparable to
Plug in Hybrid Electric Vehicle. This vehicle type can be used solely on electricity
charged by plugging in or solely on electricity generated by fuel cell.
Plug-in fuel cell electric vehicles (PFCEVs) combine features of battery electric
vehicles (BEVs) and fuel cell electric vehicles (FCEVs). With a 40-mile battery
electric range (BER), the PFCEV provides unusually efficient driving.
The fuel cell and hydrogen fuel facilitate long range and quick refueling, removing range
limitations.
