Hatchback, 5 Doors, 5 Seats
100 Hp @ 4500-6000 rpm.
100.2 Hp/l
185 km/h 114.95 mph
998 cm3
60.9 cu. in.
3, Inline
Front wheel drive,
4065 mm
160.04 in.
1775 mm
69.88 in.
1090-1200 kg
2403.04 - 2645.55 lbs.
| Brand | Hyundai |
|---|---|
| Model | i20 (Hatchback) |
| Version | i20 III (facelift 2023) |
| Engine version | 1.0 T-GDi (100 Hp) DCT |
| Year production start | 2023 |
| Vehicle type | Hatchback |
| Horsepower RPM | 100 Hp @ 4500-6000 rpm. |
| Acceleration 0 - 100 kmh sec | 11.4 sec |
| Curb weight kg -lbs total |
1090-1200 kg2403.04 - 2645.55 lbs. |
| Overall length mm - inch |
4065 mm160.04 in. |
| Doors | 5 |
| Top Speed | 185 km/h 114.95 mph |
| Designation model | G3LE |
|---|---|
| Cam configuration | DOHC |
| Engine position and orientation | Front, Transverse |
| Cylinders | 3 |
| Position of cylinders | Inline |
| Displacement (liters) |
998 cm360.9 cu. in. |
| Eng. horsepower RPM | 100 Hp @ 4500-6000 rpm. |
| Horsepower per litre | 100.2 Hp/l |
| Weight / horsepower kg/hp - hp/tons |
10.9 kg/Hp91.7 Hp/tonne |
| Weight / torque kg/Nm - Nm/tons | 6.3 kg/Nm, 157.8 Nm/tonne
6.3 kg/Nm157.8 Nm/tonne |
| Torque Nm RPM lb-ft RPM |
172 Nm @ 1500-4000 rpm.126.86 lb.-ft. @ 1500-4000 rpm. |
| Bore (mm in) |
71 mm2.8 in. |
| Stroke (mm in) |
84 mm3.31 in. |
| Compression ratio | 10.5 |
| Fuel type | Petrol (Gasoline) |
| Valvetrain | 4 |
| Engine aspiration | Turbocharger, Intercooler |
| Engine oil liters | quarts |
3.6 l3.8 US qt | 3.17 UK qt |
| Engine coolant |
5.77 l6.1 US qt | 5.08 UK qt |
| Emission certification | Euro 6D |
| Powertrain architecture | Internal Combustion engine |
| Drive configuration | Front wheel drive |
|---|
| Front brakes | Ventilated discs, 280 mm |
|---|---|
| Rear brakes | Disc, 262 mm |
| Anti-lock brake system | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
|---|---|
| Turning diameter m - ft |
10.4 m34.12 ft. |
| Front suspension | Independent type McPherson |
|---|---|
| Rear suspension | Torsion |
| Wheels size | 195/55 R16; 215/45 R17 |
|---|---|
| Wheels rims | 6.0J x 16; 7.0J x 17 |
| Passengers seats | 5 |
|---|---|
| Trunk space min liter | cu. Ft. |
352 l12.43 cu. ft. |
| Trunk space max liter | cu. Ft. |
1165 l41.14 cu. ft. |
| Roof load load kg lbs |
70 kg154.32 lbs. |
| Overall length mm - inch |
4065 mm160.04 in. |
|---|---|
| Overall width mm -inch |
1775 mm69.88 in. |
| Overall height mm -inch |
1450 mm57.09 in. |
| Wheelbase mm - inch |
2580 mm101.57 in. |
| Track width front mm - inch |
1531-1539 mm60.28 - 60.59 in. |
| Track width rear mm - inch |
1536-1543 mm60.47 - 60.75 in. |
| Curb weight kg -lbs total |
1090-1200 kg2403.04 - 2645.55 lbs. |
|---|---|
| Gross weight kg -lbs total |
1630 kg3593.53 lbs. |
| Capacities kg - lbs |
430-540 kg947.99 - 1190.5 lbs. |
| Fuel tank liters | gallons |
40 l10.57 US gal | 8.8 UK gal |
