Station wagon (estate), 5 Doors, 5 Seats
6.5 l/100 km 36.19 US mpg
8.9 l/100 km 26.43 US mpg
5.2 l/100 km 45.23 US mpg
142 Hp @ 6500 rpm.
79 Hp/l
205 km/h 127.38 mph
1798 cm3
109.72 cu. in.
4, Inline
Front wheel drive,
4590 mm
180.71 in.
1770 mm
69.69 in.
1388 kg
3060.02 lbs.
| Brand | Honda |
|---|---|
| Model | Civic (Station wagon (estate)) |
| Version | Civic IX Tourer (facelift 2014) |
| Engine version | 1.8 i-VTEC (142 Hp) Automatic |
| Year production start | 2014 |
| Year production end | 2017 |
| Vehicle type | Station wagon (estate) |
| Horsepower RPM | 142 Hp @ 6500 rpm. |
| Acceleration 0 - 100 kmh sec | 11.1 sec |
| Curb weight kg -lbs total |
1388 kg3060.02 lbs. |
| Overall length mm - inch |
4590 mm180.71 in. |
| Doors | 5 |
| Top Speed | 205 km/h 127.38 mph |
| Cam configuration | SOHC |
|---|---|
| Engine position and orientation | Front, Transverse |
| Cylinders | 4 |
| Position of cylinders | Inline |
| Displacement (liters) |
1798 cm3109.72 cu. in. |
| Eng. horsepower RPM | 142 Hp @ 6500 rpm. |
| Horsepower per litre | 79 Hp/l |
| Weight / horsepower kg/hp - hp/tons |
9.8 kg/Hp102.3 Hp/tonne |
| Weight / torque kg/Nm - Nm/tons | 8 kg/Nm, 125.4 Nm/tonne
8 kg/Nm125.4 Nm/tonne |
| Torque Nm RPM lb-ft RPM |
174 Nm @ 4300 rpm.128.34 lb.-ft. @ 4300 rpm. |
| Bore (mm in) |
81 mm3.19 in. |
| Stroke (mm in) |
87.3 mm3.44 in. |
| Compression ratio | 10.6 |
| Fuel delivery system | Multi-point indirect injection |
| Fuel type | Petrol (Gasoline) |
| Valvetrain | 4 |
| Engine aspiration | Naturally aspirated engine |
| Emission certification | Euro 6 |
| Powertrain architecture | Internal Combustion engine |
| Engine location | Front, Transverse |
| Drive configuration | Front wheel drive |
|---|
| Front brakes | Ventilated discs |
|---|---|
| Rear brakes | Disc |
| Anti-lock brake system | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
|---|---|
| Turning diameter m - ft |
11.28 m37.01 ft. |
| Front suspension | Independent type McPherson |
|---|---|
| Rear suspension | Semi-independent, coil spring |
| Wheels size | 205/55R16 88V |
|---|---|
| Wheels rims | 6.5J x 16 |
| Passengers seats | 5 |
|---|
| Overall length mm - inch |
4590 mm180.71 in. |
|---|---|
| Overall width mm -inch |
1770 mm69.69 in. |
| Wheelbase mm - inch |
2595 mm102.17 in. |
| Track width front mm - inch |
1530 mm60.24 in. |
| Track width rear mm - inch |
1530 mm60.24 in. |
| Curb weight kg -lbs total |
1388 kg3060.02 lbs. |
|---|---|
| Gross weight kg -lbs total |
1830 kg4034.46 lbs. |
| Capacities kg - lbs |
442 kg974.44 lbs. |
| Fuel tank liters | gallons |
50 l13.21 US gal | 11 UK gal |
| City l/100km - mpg |
8.9 l/100 km26.43 US mpg |
|---|---|
| Highway l/100 km - mpg |
5.2 l/100 km45.23 US mpg |
| Combined l/100 km - Mpg |
6.5 l/100 km36.19 US mpg |
| Autonomy km (combined use) | 769 |
