Hatchback, 5 Doors, 5 Seats
6 l/100 km 39.2 US mpg
112 Hp @ 6300 rpm.
74.7 Hp/l
175 km/h 108.74 mph
1499 cm3
91.47 cu. in.
4, Inline
Front wheel drive,
3886 mm
152.99 in.
1695 mm
66.73 in.
#N/D
| Brand | Ford |
|---|---|
| Model | Figo (Hatchback) |
| Version | Figo II |
| Engine version | 1.5 Ti-VCT (112 Hp) DCT |
| Year production start | 2015 |
| Year production end | 2018 |
| Vehicle type | Hatchback |
| Horsepower RPM | 112 Hp @ 6300 rpm. |
| Acceleration 0 - 100 kmh sec | 12 sec |
| Overall length mm - inch |
3886 mm152.99 in. |
| Doors | 5 |
| Top Speed | 175 km/h 108.74 mph |
| Cam configuration | Ti-VCT |
|---|---|
| Engine position and orientation | Front, Transverse |
| Cylinders | 4 |
| Position of cylinders | Inline |
| Displacement (liters) |
1499 cm391.47 cu. in. |
| Eng. horsepower RPM | 112 Hp @ 6300 rpm. |
| Horsepower per litre | 74.7 Hp/l |
| Torque Nm RPM lb-ft RPM |
136 Nm @ 4250 rpm.100.31 lb.-ft. @ 4250 rpm. |
| Compression ratio | 11 |
| Fuel delivery system | Multi-point indirect injection |
| Fuel type | Petrol (Gasoline) |
| Valvetrain | 4 |
| Engine aspiration | Naturally aspirated engine |
| Powertrain architecture | Internal Combustion engine |
| Engine location | Front, Transverse |
| Drive configuration | Front wheel drive |
|---|
| Front brakes | Ventilated discs |
|---|---|
| Rear brakes | Drum |
| Anti-lock brake system | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
|---|---|
| Turning diameter m - ft |
9.8 m32.15 ft. |
| Front suspension | Independent, Spring McPherson, with stabilizer |
|---|---|
| Rear suspension | Semi-independent, coil spring |
| Wheels size | 175/65 R14 |
|---|---|
| Wheels rims | 14 |
| Passengers seats | 5 |
|---|---|
| Trunk space min liter | cu. Ft. |
257 l9.08 cu. ft. |
| Overall length mm - inch |
3886 mm152.99 in. |
|---|---|
| Overall width mm -inch |
1695 mm66.73 in. |
| Overall height mm -inch |
1525 mm60.04 in. |
| Wheelbase mm - inch |
2491 mm98.07 in. |
| Track width front mm - inch |
1492 mm58.74 in. |
| Track width rear mm - inch |
1484 mm58.43 in. |
| Fuel tank liters | gallons |
42 l11.1 US gal | 9.24 UK gal |
|---|
| Combined l/100 km - Mpg |
6 l/100 km39.2 US mpg |
|---|---|
| Autonomy km (combined use) | #VALORE! |
