Minivan, 5 Doors, 7 Seats
7 l/100 km 33.6 US mpg
9.3 l/100 km 25.29 US mpg
5.7 l/100 km 41.27 US mpg
163 Hp @ 3800 rpm.
81.6 Hp/l
195 km/h 121.17 mph
1998 cm3
121.93 cu. in.
4, Inline
Front wheel drive,
4652 mm
183.15 in.
1836 mm
72.28 in.
1659 kg
3657.47 lbs.
| Brand | Chevrolet |
|---|---|
| Model | Orlando (Minivan) |
| Version | Orlando I |
| Engine version | 2.0 TD (163 Hp) Automatic |
| Year production start | 2011 |
| Year production end | 2018 |
| Vehicle type | Minivan |
| Horsepower RPM | 163 Hp @ 3800 rpm. |
| Acceleration 0 - 100 kmh sec | 11 sec |
| Curb weight kg -lbs total |
1659 kg3657.47 lbs. |
| Overall length mm - inch |
4652 mm183.15 in. |
| Doors | 5 |
| Top Speed | 195 km/h 121.17 mph |
| Cam configuration | DOHC |
|---|---|
| Engine position and orientation | Front, Transverse |
| Cylinders | 4 |
| Position of cylinders | Inline |
| Displacement (liters) |
1998 cm3121.93 cu. in. |
| Eng. horsepower RPM | 163 Hp @ 3800 rpm. |
| Horsepower per litre | 81.6 Hp/l |
| Weight / horsepower kg/hp - hp/tons |
10.2 kg/Hp98.3 Hp/tonne |
| Weight / torque kg/Nm - Nm/tons | 4.6 kg/Nm, 217 Nm/tonne
4.6 kg/Nm217 Nm/tonne |
| Torque Nm RPM lb-ft RPM |
360 Nm @ 2000 rpm.265.52 lb.-ft. @ 2000 rpm. |
| Bore (mm in) |
86 mm3.39 in. |
| Stroke (mm in) |
86 mm3.39 in. |
| Compression ratio | 16.3 |
| Fuel delivery system | Diesel Commonrail |
| Fuel type | Diesel |
| Valvetrain | 4 |
| Engine aspiration | Turbocharger, Intercooler |
| Emission certification | Euro 5 |
| Powertrain architecture | Internal Combustion engine |
| Engine location | Front, Transverse |
| Drive configuration | Front wheel drive |
|---|
| Front brakes | Disc |
|---|---|
| Anti-lock brake system | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
|---|---|
| Turning diameter m - ft |
11.3 m37.07 ft. |
| Front suspension | Independent type McPherson |
|---|---|
| Rear suspension | Torsion |
| Wheels size | 215/R60 R16 |
|---|---|
| Wheels rims | 16 |
| Passengers seats | 7 |
|---|---|
| Trunk space min liter | cu. Ft. |
89 l3.14 cu. ft. |
| Trunk space max liter | cu. Ft. |
458 l16.17 cu. ft. |
| Overall length mm - inch |
4652 mm183.15 in. |
|---|---|
| Overall width mm -inch |
1836 mm72.28 in. |
| Overall height mm -inch |
1633 mm64.29 in. |
| Wheelbase mm - inch |
2760 mm108.66 in. |
| Track width front mm - inch |
1584 mm62.36 in. |
| Track width rear mm - inch |
1588 mm62.52 in. |
| Curb weight kg -lbs total |
1659 kg3657.47 lbs. |
|---|---|
| Gross weight kg -lbs total |
2291 kg5050.79 lbs. |
| Capacities kg - lbs |
632 kg1393.32 lbs. |
| Fuel tank liters | gallons |
64 l16.91 US gal | 14.08 UK gal |
| City l/100km - mpg |
9.3 l/100 km25.29 US mpg |
|---|---|
| Highway l/100 km - mpg |
5.7 l/100 km41.27 US mpg |
| Combined l/100 km - Mpg |
7 l/100 km33.6 US mpg |
| Autonomy km (combined use) | #VALORE! |
