Key specs
Chevrolet Agile (Hatchback) Agile 2009,2010,2011,2012,2013,2014,2015,2016
What is the body type, Chevrolet Agile 1.4 Econo.Flex (102 Hp) Easytronic 2009?
Hatchback, 5 Doors, 5 Seats
How much power, Chevrolet Agile 1.4 Econo.Flex (102 Hp) Easytronic 2009?
102 Hp @ 6000 rpm.
73.4 Hp/l
What is the engine size, Chevrolet Agile 1.4 Econo.Flex (102 Hp) Easytronic 2009?
1389 cm3
84.76 cu. in.
How many cylinders, Chevrolet Agile 1.4 Econo.Flex (102 Hp) Easytronic 2009?
4,
Inline
What is the drivetrain, Chevrolet Agile 1.4 Econo.Flex (102 Hp) Easytronic 2009?
Front wheel drive,
How long is this vehicle, Chevrolet Agile 1.4 Econo.Flex (102 Hp) Easytronic 2009?
4063 mm
159.96 in.
How wide is the vehicle, Chevrolet Agile 1.4 Econo.Flex (102 Hp) Easytronic 2009?
1683 mm
66.26 in.
What is the curb weight, Chevrolet Agile 1.4 Econo.Flex (102 Hp) Easytronic 2009?
1083-1093 kg
2387.61 - 2409.65 lbs.
Chevrolet Agile (Hatchback) Agile 2009,2010,2011,2012,2013,2014,2015,2016 Specs
General information
| Brand |
Chevrolet |
| Model |
Agile (Hatchback) |
| Version |
Agile |
| Engine version |
1.4 Econo.Flex (102 Hp) Easytronic |
| Year production start |
2009 |
| Year production end |
2016 |
| Vehicle type |
Hatchback |
| Horsepower RPM |
102 Hp @ 6000 rpm. |
| Curb weight kg -lbs total |
1083-1093 kg
2387.61 - 2409.65 lbs.
|
| Overall length mm - inch |
4063 mm
159.96 in.
|
| Doors |
5 |
Engine specs
| Engine position and orientation |
Front, Transverse |
| Cylinders |
4 |
| Position of cylinders |
Inline |
| Displacement (liters) |
1389 cm3
84.76 cu. in.
|
| Eng. horsepower RPM |
102 Hp @ 6000 rpm.
|
| Horsepower per litre |
73.4 Hp/l
|
| Weight / horsepower kg/hp - hp/tons |
10.6 kg/Hp
94.2 Hp/tonne
|
| Weight / torque kg/Nm - Nm/tons |
8.2 kg/Nm, 121.9 Nm/tonne
8.2 kg/Nm
121.9 Nm/tonne
|
| Torque Nm RPM lb-ft RPM |
132 Nm @ 3200 rpm.
97.36 lb.-ft. @ 3200 rpm.
|
| Bore (mm in) |
77.6 mm
3.06 in.
|
| Stroke (mm in) |
73.4 mm
2.89 in.
|
| Compression ratio |
12.4 |
| Fuel delivery system |
Multi-point indirect injection |
| Fuel type |
Petrol / Ethanol - E85 |
| Valvetrain |
2 |
| Engine aspiration |
Naturally aspirated engine |
| Engine coolant |
5.5 l
5.81 US qt | 4.84 UK qt
|
| Powertrain architecture |
Internal Combustion engine |
| Engine location |
Front, Transverse
|
Transmission and Drive system
| Drive configuration |
Front wheel drive
|
Brakes
| Front brakes |
Ventilated discs |
| Rear brakes |
Drum |
| Anti-lock brake system |
ABS (Anti-lock braking system) |
Steering
| Steering type |
Steering rack and pinion |
| Turning diameter m - ft |
10.65 m
34.94 ft.
|
Suspension
| Front suspension |
Independent type McPherson |
| Rear suspension |
Torsion |
Wheels & Tyres
| Wheels size |
195/55 R16
|
| Wheels rims |
6J x 16 |
Dimensions
| Overall length mm - inch |
4063 mm
159.96 in.
|
| Overall width mm -inch |
1683 mm
66.26 in.
|
| Overall height mm -inch |
1549 mm
60.98 in.
|
| Wheelbase mm - inch |
2543 mm
100.12 in.
|
| Track width front mm - inch |
1437 mm
56.57 in.
|
| Track width rear mm - inch |
1438 mm
56.61 in.
|
Weights
| Curb weight kg -lbs total |
1083-1093 kg
2387.61 - 2409.65 lbs.
|
| Gross weight kg -lbs total |
1462 kg
3223.16 lbs.
|
| Capacities kg - lbs |
369-379 kg
813.51 - 835.55 lbs.
|
| Fuel tank liters | gallons |
54 l
14.27 US gal | 11.88 UK gal
|
Engine type
4 CYLINDER INLINE
