Key specs
BMW X1 (SAV) X1 (U11) 2022,2023,2024
What is the body type, BMW X1 (U11) 23d (211 Hp) MHEV sDrive Steptronic 2022?
SAV, 5 Doors, 5 Seats
How much power, BMW X1 (U11) 23d (211 Hp) MHEV sDrive Steptronic 2022?
197 Hp @ 4000 rpm.
98.7 Hp/l
How fast is the car, BMW X1 (U11) 23d (211 Hp) MHEV sDrive Steptronic 2022?
225 km/h 139.81 mph
What is the engine size, BMW X1 (U11) 23d (211 Hp) MHEV sDrive Steptronic 2022?
1995 cm3
121.74 cu. in.
How many cylinders, BMW X1 (U11) 23d (211 Hp) MHEV sDrive Steptronic 2022?
4,
Inline
What is the drivetrain, BMW X1 (U11) 23d (211 Hp) MHEV sDrive Steptronic 2022?
Front wheel drive,
How long is this vehicle, BMW X1 (U11) 23d (211 Hp) MHEV sDrive Steptronic 2022?
4500 mm
177.17 in.
How wide is the vehicle, BMW X1 (U11) 23d (211 Hp) MHEV sDrive Steptronic 2022?
1845 mm
72.64 in.
What is the curb weight, BMW X1 (U11) 23d (211 Hp) MHEV sDrive Steptronic 2022?
1690 kg
3725.81 lbs.
BMW X1 (SAV) X1 (U11) 2022,2023,2024 Specs
General information
| Brand |
BMW |
| Model |
X1 (SAV) |
| Version |
X1 (U11) |
| Engine version |
23d (211 Hp) MHEV sDrive Steptronic |
| Year production start |
2022 |
| Vehicle type |
SAV |
| Horsepower RPM |
197 Hp @ 4000 rpm. |
| Acceleration 0 - 100 kmh sec |
7.4 sec |
| Curb weight kg -lbs total |
1690 kg
3725.81 lbs.
|
| Overall length mm - inch |
4500 mm
177.17 in.
|
| Doors |
5 |
| Top Speed |
225 km/h 139.81 mph |
Engine specs
| Designation model |
B47 |
| Cam configuration |
DOHC
|
| Engine position and orientation |
Front, Longitudinal |
| Cylinders |
4 |
| Position of cylinders |
Inline |
| Displacement (liters) |
1995 cm3
121.74 cu. in.
|
| Eng. horsepower RPM |
197 Hp @ 4000 rpm.
|
| Horsepower per litre |
98.7 Hp/l
|
| Weight / horsepower kg/hp - hp/tons |
8 kg/Hp
124.9 Hp/tonne
|
| Weight / torque kg/Nm - Nm/tons |
4.2 kg/Nm, 236.7 Nm/tonne
4.2 kg/Nm
236.7 Nm/tonne
|
| Torque Nm RPM lb-ft RPM |
400 Nm @ 1500-2750 rpm.
295.02 lb.-ft. @ 1500-2750 rpm.
|
| Bore (mm in) |
84 mm
3.31 in.
|
| Stroke (mm in) |
90 mm
3.54 in.
|
| Compression ratio |
16.5 |
| Fuel type |
Diesel |
| Valvetrain |
4 |
| Engine aspiration |
Twin-power turbo, Intercooler |
| Engine oil liters | quarts |
6.5 l
6.87 US qt | 5.72 UK qt
|
| Emission certification |
Euro 6d
|
| Powertrain architecture |
MHEV (Mild Hybrid Electric Vehicle, power-assist hybrid, battery-assisted hybrid vehicles, BAHV) |
| Electric motor power |
19 Hp
|
| Electric motor torque |
55 Nm 40.57 lb.-ft.
|
| Engine location |
Front, Longitudinal
|
| Total available power |
211 Hp
|
| Totale available torque |
400 Nm 295.02 lb.-ft.
|
Transmission and Drive system
| Drive configuration |
Front wheel drive
|
Brakes
| Front brakes |
Ventilated discs |
| Rear brakes |
Disc |
| Anti-lock brake system |
ABS (Anti-lock braking system) |
Steering
| Steering type |
Steering rack and pinion |
| Turning diameter m - ft |
11.7 m
38.39 ft.
|
Suspension
| Front suspension |
Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension |
Independent multi-link suspension |
Wheels & Tyres
| Wheels size |
205/65 R17
|
| Wheels rims |
7J x 17 |
Passenger
| Passengers seats |
5 |
| Trunk space min liter | cu. Ft. |
500 l
17.66 cu. ft.
|
| Trunk space max liter | cu. Ft. |
1545 l
54.56 cu. ft.
|
| Roof load load kg lbs |
75 kg
165.35 lbs.
|
Dimensions
| Overall length mm - inch |
4500 mm
177.17 in.
|
| Overall width mm -inch |
1845 mm
72.64 in.
|
| Overall height mm -inch |
1642 mm
64.65 in.
|
| Wheelbase mm - inch |
2692 mm
105.98 in.
|
| Track width front mm - inch |
1592 mm
62.68 in.
|
| Track width rear mm - inch |
1593 mm
62.72 in.
|
| Coefficient of drag |
0.27
|
Weights
| Curb weight kg -lbs total |
1690 kg
3725.81 lbs.
|
| Gross weight kg -lbs total |
2265 kg
4993.47 lbs.
|
| Capacities kg - lbs |
575 kg
1267.66 lbs.
|
| Fuel tank liters | gallons |
45 l
11.89 US gal | 9.9 UK gal
|
Fuel economy
| Combined fuel consumption (WLTP) |
4.8-5.3 l/100 km 49 - 44.38 US mpg |
Engine type
4 CYLINDER INLINE
