Key specs
BMW M3 (Sedan) M3 (G80) 2020,2021,2022,2023,2024
What is the body type, BMW M3 (G80) Competition 3.0 (510 Hp) Steptronic 2020?
Sedan, 4 Doors, 5 Seats
How much power, BMW M3 (G80) Competition 3.0 (510 Hp) Steptronic 2020?
510 Hp @ 6250 rpm.
170.4 Hp/l
How fast is the car, BMW M3 (G80) Competition 3.0 (510 Hp) Steptronic 2020?
250 km/h, Electronically limited 155.34 mph
What is the engine size, BMW M3 (G80) Competition 3.0 (510 Hp) Steptronic 2020?
2993 cm3
182.64 cu. in.
How many cylinders, BMW M3 (G80) Competition 3.0 (510 Hp) Steptronic 2020?
6,
Inline
What is the drivetrain, BMW M3 (G80) Competition 3.0 (510 Hp) Steptronic 2020?
Rear wheel drive,
How long is this vehicle, BMW M3 (G80) Competition 3.0 (510 Hp) Steptronic 2020?
4794 mm
188.74 in.
How wide is the vehicle, BMW M3 (G80) Competition 3.0 (510 Hp) Steptronic 2020?
1903 mm
74.92 in.
What is the curb weight, BMW M3 (G80) Competition 3.0 (510 Hp) Steptronic 2020?
1730 kg
3814 lbs.
BMW M3 (Sedan) M3 (G80) 2020,2021,2022,2023,2024 Specs
General information
| Brand |
BMW |
| Model |
M3 (Sedan) |
| Version |
M3 (G80) |
| Engine version |
Competition 3.0 (510 Hp) Steptronic |
| Year production start |
2020 |
| Vehicle type |
Sedan |
| Horsepower RPM |
510 Hp @ 6250 rpm. |
| Acceleration 0 - 100 kmh sec |
3.9 sec |
| Curb weight kg -lbs total |
1730 kg
3814 lbs.
|
| Overall length mm - inch |
4794 mm
188.74 in.
|
| Doors |
4 |
| Top Speed |
250 km/h, Electronically limited 155.34 mph |
Engine specs
| Cam configuration |
DOHC
|
| Engine position and orientation |
Front, Longitudinal |
| Cylinders |
6 |
| Position of cylinders |
Inline |
| Displacement (liters) |
2993 cm3
182.64 cu. in.
|
| Eng. horsepower RPM |
510 Hp @ 6250 rpm.
|
| Horsepower per litre |
170.4 Hp/l
|
| Weight / horsepower kg/hp - hp/tons |
3.4 kg/Hp
294.8 Hp/tonne
|
| Weight / torque kg/Nm - Nm/tons |
2.7 kg/Nm, 375.7 Nm/tonne
2.7 kg/Nm
375.7 Nm/tonne
|
| Torque Nm RPM lb-ft RPM |
650 Nm @ 2750-5500 rpm.
479.42 lb.-ft. @ 2750-5500 rpm.
|
| Bore (mm in) |
84 mm
3.31 in.
|
| Stroke (mm in) |
90 mm
3.54 in.
|
| Compression ratio |
9.3 |
| Fuel delivery system |
Direct injection |
| Fuel type |
Petrol (Gasoline) |
| Valvetrain |
4 |
| Engine aspiration |
Twin-power turbo, Intercooler |
| Engine oil liters | quarts |
7 l
7.4 US qt | 6.16 UK qt
|
| Emission certification |
Euro 6d
|
| Powertrain architecture |
Internal Combustion engine |
| Engine location |
Front, Longitudinal
|
Transmission and Drive system
| Drive configuration |
Rear wheel drive
|
Brakes
| Front brakes |
Ventilated discs |
| Rear brakes |
Ventilated discs |
| Brake control |
Ventilated discs |
| Anti-lock brake system |
ABS (Anti-lock braking system) |
Steering
| Steering type |
Steering rack and pinion |
| Turning diameter m - ft |
12.2 m
40.03 ft.
|
Suspension
| Front suspension |
Coil spring, Double wishbone |
| Rear suspension |
Independent multi-link |
Wheels & Tyres
| Wheels size |
Front wheel tires: 275/40 ZR18 103Y XL
|
| Wheels rims |
Front wheel rims: 9.5J x 18 |
Passenger
| Passengers seats |
5 |
| Trunk space min liter | cu. Ft. |
480 l
16.95 cu. ft.
|
| Roof load load kg lbs |
75 kg
165.35 lbs.
|
Dimensions
| Overall length mm - inch |
4794 mm
188.74 in.
|
| Overall width mm -inch |
1903 mm
74.92 in.
|
| Overall height mm -inch |
1433 mm
56.42 in.
|
| Wheelbase mm - inch |
2857 mm
112.48 in.
|
| Track width front mm - inch |
1617 mm
63.66 in.
|
| Track width rear mm - inch |
1605 mm
63.19 in.
|
| Coefficient of drag |
0.33
|
Weights
| Curb weight kg -lbs total |
1730 kg
3814 lbs.
|
| Gross weight kg -lbs total |
2210 kg
4872.22 lbs.
|
| Capacities kg - lbs |
480 kg
1058.22 lbs.
|
| Fuel tank liters | gallons |
59 l
15.59 US gal | 12.98 UK gal
|
Fuel economy
| Urban (NEDC) l/100 km - Mpg |
14.6 l/100 km
16.11 US mpg
|
| Extra urban (NEDC) l/100 km - Mpg |
7.6 l/100 km
30.95 US mpg
|
| Combined (NEDC) l/100 km - Mpg |
10.2 l/100 km
23.06 US mpg
|
| Autonomy km (combined use) NEDC |
5900 |
| Combined fuel consumption (WLTP) |
10.0-10.2 l/100 km 23.52 - 23.06 US mpg |
Engine type
6 CYLINDER INLINE
