Grand Tourer, 5 Doors, 5 Seats
5.5 l/100 km 42.77 US mpg
6.2 l/100 km 37.94 US mpg
5 l/100 km 47.04 US mpg
184 Hp @ 4000 rpm.
92.2 Hp/l
215 km/h 133.59 mph
1995 cm3
121.74 cu. in.
4, Inline
Rear wheel drive,
5004 mm
197.01 in.
1901 mm
74.84 in.
1915 kg
4221.85 lbs.
| Brand | BMW |
|---|---|
| Model | 5 Series (Grand Tourer) |
| Version | 5 Series Gran Turismo (F07 LCI, Facelift 2013) |
| Engine version | 520d (184 Hp) Steptronic |
| Year production start | 2013 |
| Year production end | 2017 |
| Vehicle type | Grand Tourer |
| Horsepower RPM | 184 Hp @ 4000 rpm. |
| Acceleration 0 - 100 kmh sec | 8.9 sec |
| Curb weight kg -lbs total |
1915 kg4221.85 lbs. |
| Overall length mm - inch |
5004 mm197.01 in. |
| Doors | 5 |
| Top Speed | 215 km/h 133.59 mph |
| Designation model | N47D20 |
|---|---|
| Engine position and orientation | Front, Longitudinal |
| Cylinders | 4 |
| Position of cylinders | Inline |
| Displacement (liters) |
1995 cm3121.74 cu. in. |
| Eng. horsepower RPM | 184 Hp @ 4000 rpm. |
| Horsepower per litre | 92.2 Hp/l |
| Weight / horsepower kg/hp - hp/tons |
10.4 kg/Hp96.1 Hp/tonne |
| Weight / torque kg/Nm - Nm/tons | 5 kg/Nm, 198.4 Nm/tonne
5 kg/Nm198.4 Nm/tonne |
| Torque Nm RPM lb-ft RPM |
380 Nm @ 1750-2750 rpm.280.27 lb.-ft. @ 1750-2750 rpm. |
| Bore (mm in) |
84 mm3.31 in. |
| Stroke (mm in) |
90 mm3.54 in. |
| Compression ratio | 16.5 |
| Fuel delivery system | Diesel Commonrail |
| Fuel type | Diesel |
| Valvetrain | 4 |
| Engine aspiration | Twin-power turbo, Intercooler |
| Engine oil liters | quarts |
5.2 l5.49 US qt | 4.58 UK qt |
| Engine coolant |
8.4 l8.88 US qt | 7.39 UK qt |
| Emission certification | Euro 6 |
| Powertrain architecture | Internal Combustion engine |
| Engine location | Front, Longitudinal |
| Drive configuration | Rear wheel drive |
|---|
| Front brakes | Ventilated discs |
|---|---|
| Rear brakes | Ventilated discs |
| Brake control | Ventilated discs |
| Anti-lock brake system | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
|---|---|
| Turning diameter m - ft |
12.2 m40.03 ft. |
| Front suspension | Double wishbone |
|---|---|
| Rear suspension | Multi-link independent |
| Wheels size | 245/50 R18 100Y |
|---|---|
| Wheels rims | 8J x 18 |
| Passengers seats | 5 |
|---|---|
| Trunk space min liter | cu. Ft. |
500 l17.66 cu. ft. |
| Trunk space max liter | cu. Ft. |
1700 l60.03 cu. ft. |
| Roof load load kg lbs |
75 kg165.35 lbs. |
| Overall length mm - inch |
5004 mm197.01 in. |
|---|---|
| Overall width mm -inch |
1901 mm74.84 in. |
| Overall height mm -inch |
1559 mm61.38 in. |
| Wheelbase mm - inch |
3070 mm120.87 in. |
| Track width front mm - inch |
1611 mm63.43 in. |
| Track width rear mm - inch |
1654 mm65.12 in. |
| Coefficient of drag | 0.29 |
| Curb weight kg -lbs total |
1915 kg4221.85 lbs. |
|---|---|
| Gross weight kg -lbs total |
2545 kg5610.76 lbs. |
| Capacities kg - lbs |
630 kg1388.91 lbs. |
| Fuel tank liters | gallons |
70 l18.49 US gal | 15.4 UK gal |
| City l/100km - mpg |
6.2 l/100 km37.94 US mpg |
|---|---|
| Highway l/100 km - mpg |
5 l/100 km47.04 US mpg |
| Combined l/100 km - Mpg |
5.5 l/100 km42.77 US mpg |
| Autonomy km (combined use) | 1273 |
